Challenger EV1020 10,000 lb Inground Lift

SKU: EV1020

Ships from manufacturer

Electric/Hydraulic Inground Lift With 8.5 In. Chrome Pistons, Wide Drive-Through 3-Stage Arms And Double Telescoping Screw Pads

Complete 10,000 lb Inground Lift System

The Challenger EV1020 is a complete inground lift system designed for new construction and major renovation projects. This full system includes hydraulic cylinders, lifting adapters, control unit, and all necessary hardware for installation in concrete pits. Once lowered, the lift sits flush with your facility floor, eliminating any above-ground obstructions and maintaining a clean, uncluttered workspace.

Installation & Operation

This electric/hydraulic lift operates on standard 220V single-phase power. The cylinders install directly into concrete pits, and the control unit provides intuitive operation for lifting and lowering vehicles. The flush-mount design is ideal for professional service bays where space efficiency and safety are critical.

Capacity & Specifications

With a 10,000 lb lifting capacity, the EV1020 handles sedans, coupes, crossovers, and lighter SUVs with ease. The system is engineered for durability and reliable performance in high-traffic service environments.

Features & Benefits

Complete Full System

Includes all components for installation

  • Hydraulic cylinders
  • Lifting adapters
  • Control unit

220V Electric/Hydraulic Operation

Standard commercial power requirements

  • Single-phase 220V
  • Energy efficient
  • Smooth cycling

Flush-Mount Design

Seamless integration with facility floor

  • Concrete pit installation
  • Zero obstruction when lowered
  • Professional appearance

Professional Grade Construction

Built for demanding service environments

  • Heavy-duty cylinders
  • Durable components
  • Long service life

10,000 lb Lifting Capacity

Suitable for most passenger vehicles

  • Sedans and coupes
  • Crossovers
  • Light SUVs

Complete Hardware & Installation

All necessary components included

  • Safety adaptors
  • Control mechanisms
  • Mounting hardware

Specifications

ModelEV1020EV1020-BMCEV1020-BMC-QCEV1020-QC
Price
$12,493.96$19,521.82
Save 36% ($7,027.86)
$13,440.00$21,000.00
Save 36% ($7,560.00)
$14,310.89$22,360.78
Save 36% ($8,049.89)
$13,435.61$20,993.16
Save 36% ($7,557.55)
Product TypeIn Ground LiftIn Ground LiftIn Ground LiftIn Ground Lift
Lifting Capacity10,000 lb lbs10,000 lb lbs10,000 lb lbs10,000 lb lbs
Lift ConfigurationStandard IngroundStandard IngroundStandard IngroundStandard Inground
Rise Height74" "74" "74" "74" "
Arms3-stage front/3-stage rear3-stage front/3-stage rear3-stage front/3-stage rear3-stage front/3-stage rear
Overall Width97979797
Drive-Thru Clearance87"87"87"87"
Speed of Rise38s sec38s sec27s sec27s sec
Front Arm Reach19.625" - 42.125"19.625" - 42.125"19.625" - 42.125"19.625" - 42.125"
Screw Pad Height3.875" - 6"3.875" - 6"3.875" - 6"3.875" - 6"
Motor2HP, 208-230v, 60Hz, 1Ph HP2HP, 208-230v, 60Hz, 1Ph HP2HP, 208-230v, 60Hz, 1Ph HP2HP, 208-230v, 60Hz, 1Ph HP
ALI/ETL CertifiedYesYesYesYes
Colors AvailableRed, Blue, BlackRed, Blue, BlackRed, Blue, BlackRed, Blue, Black

Before You Buy

Professional Freight Delivery

This item ships via freight carrier with delivery to your loading dock or business address. Residential delivery and liftgate service available at checkout for an additional fee. Please inspect all packaging for visible damage before signing the delivery receipt.

Ships Within 2-5 Business Days

This item typically ships within 2-5 business days from our warehouse. Freight transit times vary by destination, generally 3-7 additional business days. You will receive tracking information via email once your order ships.

Professional Installation Recommended

Inground lift installation requires concrete work and electrical connections. We strongly recommend hiring licensed professionals for installation. Contact us for installation partner recommendations in your area.

Frequently Asked Questions

The EV1020 has a 10,000 lb capacity and safely lifts sedans, coupes, crossovers, and light SUVs. Verify your vehicle weight against the 10,000 lb rating before use.
This is a complete full system. It includes hydraulic cylinders, lifting adapters, control unit, and all hardware needed for installation. No additional major components are required.
The system operates on standard 220V single-phase power. Your facility must have appropriate electrical infrastructure installed by a licensed electrician.
Yes, the cylinders are designed to install in concrete pits. The installation process requires concrete cutting and pit preparation, typically handled during new construction or major renovation.
The EV1020 features a flush-mount design. When fully lowered, the lift sits level with your facility floor, creating a seamless, obstruction-free workspace.
Installation timelines vary based on facility conditions and concrete work required. Most installations are completed within 2-4 weeks from delivery. We recommend consulting with our installation specialists for your specific project.
Yes, the complete system includes lifting adapters. However, you may want to verify compatibility with your specific vehicle models and have additional adapters available for different vehicle types.
Regular maintenance includes hydraulic fluid checks, seal inspections, and control unit testing. We recommend professional maintenance checks annually or per manufacturer guidelines.
Yes, the EV1020 is specifically designed for professional service environments. The flush-mount design and robust construction make it ideal for shops handling routine maintenance and repairs.
The system includes safety adapters and engineered control mechanisms. Always follow proper lifting procedures and verify vehicle weight before lifting. Additional safety accessories may be purchased separately.
